CCI.TECU – Operation
Note
Calibration is only possible for the active tractor. For all other tractors, the button
"Calibrate" (F3) is greyed-out.
Note
The hectare counter source can only be selected if both speed sensors are used
simultaneously (see chapter 4.3.3.3). In all other cases the "Hectare counter
source" is greyed-out.
4.3.3.4.1 Enter the wheel speed sensor value
Proceed as follows to enter the value for the pulses per 100 metres for the wheel
speed sensor:
1. Press on the "Wheel speed sensor" button on the touchscreen or turn the scroll
wheel until the button is highlighted in white and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
2. Enter the new value on the touchscreen using the digit field or the slider.
3. Confirm your entry with "OK".
Note
The valid value range for the number of pulses is between 200 and 30000
Pul/100m.
4.3.3.4.2 Enter the ground speed sensor value
Proceed as follows to enter the value for the pulses per 100 metres for the ground
speed sensor:
1. Press on the "Ground speed sensor" button on the touchscreen or turn the
scroll wheel until the button is highlighted in white and then press on the scroll
wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
2. Enter the new value on the touchscreen using the digit field or the slider.
3. Confirm your entry with "OK".
Note
The valid value range for the number of pulses is between 200 and 30000
Pul/100m.
