CCI.TECU – Operation
4.3.3.4.3 Select the hectare counter source
Note
The hectare counter source can only be selected if both speed sensors are used
simultaneously (see chapter 4.3.3.3). In all other cases the "Hectare counter
source" is greyed-out.
To select the source for the speed displayed by the hectare counter, proceed as
follows:
1. Press on the "Hectare counter source" button on the touchscreen or turn the
scroll wheel until the button is highlighted in white and then press on the scroll
wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A selection list opens.
2. For the hectare counter source select between wheel speed sensor and
ground speed sensor. To do this, press the button with the corresponding
sensor.
3. Confirm your entry with "OK".
27
