CCI.TECU – Operation
4.3.3.4.4 Calibrate
Note
Where possible the speed calibration should not be carried out on smooth surfaces
(e.g. asphalt), rather directly on the field.
In order to calibrate the speed proceed as follows:
1. Set out a distance of 100 metres.
2. Press the "Calibrate" button (F3) on the touchscreen.
A selection list opens.
3. For the calibration select between the wheel and ground speed sensors. To
do this press on the touchscreen button for the sensor whose speed is to be
calibrated or turn the scroll wheel until the button is highlighted in white and
then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
Note
The selection between wheel and ground speed sensor for the calibration is only
necessary for a terminal of hardware generation 2 (version 2.x) when both speed
sensors are being used simultaneously (see chapter 4.3.3.3).
The calibration menu opens.
4. Go to the starting point and press the "Start Flag" button (F3) on the
touchscreen.
5. Drive 100 metres and then press the "Target Flag" button (F9) on the
touchscreen.
6. Confirm the values with "OK".
Note
The valid value range for the number of pulses is between 200 and 30000
Pul/100m.
