VT50 – Operation
5.3.8.3.1 Show information
1. To view detailed information about one of the network members on the
touchscreen press the button with the sensor or turn the scroll wheel until the
button is highlighted in white and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A mask opens with the following information about the network member:
• Manufacturer
• Device Class
• Function
• Function Instance
• Source Address
5.3.8.3.2 Filter list
To filter the list of network members, proceed as follows:
1. Press the "Filter list" button (F10) on the touchscreen.
The list of network members is filtered so that only the connected and
active members are displayed.
5.3.8.3.3 Reset filter
To reset the filter setting, proceed as follows:
1. Press the "Reset filter" button (F11) on the touchscreen.
The filter is automatically reset.
5.3.8.3.4 Delete all object pools
To delete all object pools, proceed as follows:
1. Press the "Delete all object pools" button (F12) on the touchscreen.
All saved object pools are deleted.
Note
After a restart, all object pools are deleted. In the event that an implement is
connected, the new object pool is loaded automatically.
50
