VT50 – Operation
5.3.8.3.5 Delete current object pool
To delete the current object pool, proceed as follows:
1. From the list of network members select the implement with the object pool to
be deleted. To do so, press on the button with the implement name on the
touchscreen or turn the scroll wheel until the button is highlighted in white and
then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A context menu opens.
2. Press on the "Delete a specific object pool" button on the touchscreen or turn
the scroll wheel until the button is highlighted in white and then press on the
scroll wheel.
Note
Initially the object pool remains in the list after deleting, however it can no longer be
operated via the context menu. When the terminal is next restarted, it is reloaded in
case the implement is connected.
51
