VT50Operation
5.3.8.4 Storage information
To change to the storage information proceed as follows:
1. Press on the "Storage" button on the touchscreen or turn the scroll wheel until
the button is highlighted in white and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
The following mask opens:
You have the following operating options:
Show RAM
Show internal storage
Show Flash drive status
52
