VT50 – Operation
5.3.8.5.10.1 Enter the CAN trace duration
Proceed as follows to enter the CAN trace duration:
1. Press on the "Duration" button on the touchscreen or turn the scroll wheel until
the button is highlighted in white and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
2. Enter the value on the touchscreen using the digit field or the slider.
3. Confirm your entry with "OK".
Note
Values between 60 and 6000 are valid for the duration of the CAN trace.
5.3.8.5.11 Start recording
To start recording of the CAN trace, proceed as follows:
1. Press the "Start recording" button (F12) on the touchscreen.
Recording of the CAN trace is started.
Note
The duration of the recording can be defined via the duration of the CAN trace (see
chapter 5.3.8.5.10.1).
59
