CCI.Cam – Operation
4.4.3.1 Assigning the function keys
To assign a function key to a camera, proceed as follows:
1. Press on one of the "Camera 1-8" buttons on the touchscreen or turn the
scroll wheel until the button in question is highlighted in white and then press
on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A list of available function keys opens.
2. Select a function key from the list. To do this in the touchscreeen press the
button with the number of the function key.
3. Confirm your selection with "OK" or press on the button with the function key
number again.
Note
A further camera can be assigned to each of function keys 3, 4 and 5 using
function keys 3 (2), 4 (2) and 5 (2). To be able to access these other cameras via
the function keys, the button "Display other cameras" (F6) must be pressed (see
16
