CCI.Cam – Operation
4.3.1 Switch automatic camera switching on or off
If you do not want to change the display of the camera images manually, you can
switch on automatic camera switching. The display will then automatically switch to
the different camera images at regular intervals.
To switch the automatic camera switching on or off, proceed as follows:
1. Press the "Switch on automatic camera switching" button (F10) on the
touchscreen or "Switch off automatic camera switching" (F10) if this is already
switched on.
Note
Automatic camera switching can only be turned on if several camera images have
been activated for automatic mode (see chapter 4.4.4.1).
Note
It is possible to select the camera images amongst which automatic switching
takes place (see chapter 4.4.4.1) and the interval at which the camera images
change (see chapter 4.4.1).
4.3.2 Display camera image
To display the image from a specific camera, proceed as follows:
1. In the touchscreen, press on the button or the function key, to which the
desired camera image is assigned (see chapter 4.4.3.1).
The display switches to the camera image.
4.3.3 Display additional cameras
Note
The button with this function only appears, if the function keys 3 (2), 4 (2) and/or 5
(2) have had a camera assigned to them (see chapter 4.4.3).
To display additional cameras, proceed as follows:
1. Press the "Display Additional Cameras" button (F6) on the touchscreen.
The additional cameras are displayed on the buttons (F3 – F5).
Note
The "Camera 1" (F1) and "Camera 2" (F2) buttons are always displayed. These
buttons are the function keys for the images of the two most important cameras.
12
