DAILY MCA2014 4x4 BODYBUILDER INSTRUCTIONS
ELECTRONIC SUB-SYSTEMS
5.2BODYBUILDER CONNECTORS
13
Printed 603.95.994 1 Ed. - Base 05/2015
Pin Description
Cable
code
Signal
Connected
to
Remarks
7 Horn 0000
Output
Max 150 mA
BCM B/28
(t.b.d.)
BCM D/51
(t.b.d.)
Remote activation of horn
Ground = horn active
Open wire = no action
8 Multiple switch 0000
Output
(...)
BCM H/36
ISC input (Idle Speed Control) mode 1/2/3
(2)
Note: the ISC mode must be reactivated after every engine start-
up.
9 Reserved
10 Engine speed (rpm) 5587
Output
(...)
EDC K/70
Engine speed signal
(5)
4 pulses/rev.
11 Not connected
12 Not connected
(1)
Should you wish to change the value of the 2nd speed limiter, using the tool available at the IVECO Assistance Service, please note that:
The accuracy of the speed limiter is reduced at low vehicle speeds.
The accuracy of the speed limiter is reduced at low engine speeds: interference with the engine idle speed regulator is possible, partic-
ularly below 1000 rpm.
The speed limiter must only be used in 1
st
gear or in reverse gear.
The speed limiter may be adjusted in steps of 1 km/h by the IVECO Assistance Service.
The bodybuilder must check the functionality of the speed limiter for each application and is also responsible for preparing the relative
specific instructions.
(2)
The signals to the Multiple State Switch may also be simultaneous to requests coming from the Expansion Module through CAN open
(object 0x2001, sub 0x0C) or through activation of "PTO1/PTO2/PTO3 Memo Speed". The highest value prevails in the event of contempor-
aneity.
