DAILY MCA2014 4x4 ‒ BODYBUILDER INSTRUCTIONS
CHASSIS INTERVENTIONS
2.3 RUST AND PAINT PROTECTION
9
– Printed 603.95.994 – 1 Ed. - Base 05/2015
2.3 RUST AND PAINT PROTECTION
Note
All components mounted on the chassis must be painted in compliance with IVECO Standard 18-1600 Colour IC444 RAL 7021 -
70/80 gloss.
Original vehicle parts
The following tables show, respectively, the classes of coating and protection required for the original vehicle components, the
protections required for the parts not painted or in aluminium and treatments required for the painted parts.
Table 2.4 - Class of protection - IVECO Standard 18 - 1600 (Prospectus I)
Class Part requirements Examples of parts involved
A Parts in direct contact with atmospheric agents
Bodywork - Rear-view mirrors - Windscreen wipers -
Metallic structured sun visors - Metallic bumpers -
Cab hook lock - Door stop device -
Bodywork fastening elements (screws, bolts, nuts, washers), etc.
B
B2
Parts in direct contact with atmospheric agents that mainly have
structural characteristics, in clear sight
Frame and relative parts, including its fasteners
Parts below the radiator grille (class B)
External cab ramps
B1 Only for rear axles and front axles
C Parts in direct contact with atmospheric agents, not in clear view Engine and relative parts
D Parts not in direct contact with atmospheric agents
Pedals - Seat coverings - Fastening elements - etc.,
mounted inside the cab
Table 2.5 - Unpainted aluminium parts - IVECO Standard 18 - 1600 (Table IV)
Type of protection
IVECO
standard
Classes
A B - B1 - B2 C D
Stainless steel
(1)
18-0506 – – – –
Geomet
(2)
GEO 321-8
18-1101
yes –
– –
GEO 500-8
GEO 321-8 PM
GEO 321-8 PML
GEO 321-8 PL
GEO 500-8 PL
GEO 321-5
–
yes
GEO 500-5
GEO 321-5 PM
GEO 321-5 PML
GEO 321-5 PL
yes
Class B1
wheel studs
GEO 500-5 PL
Zinc coating
(3)
Fe/Zn 12 II
18-1102
– – yes yes
Fe/Zn 7 IV
Fe/Zn 12 IV
– – yes yes
Fe/Zn 7 IV LUB
Fe/Zn 7 IV S
– yes yes yes
Fe/Zn 12 IV S
Alloy Zn-Ni Fe/Zn Ni 7 VII S FIAT 9.57409 – yes yes yes
