DAILY MCA2014 4x4 ‒ BODYBUILDER INSTRUCTIONS
GENERAL INFORMATION
1.13 VEHICLE NAMES
– Printed 603.95.994 – 1 Ed. - Base 05/2015
1.13 VEHICLE NAMES
The commercial name of IVECO vehicles (for example NEW DAILY 35-170) does not match the type approval name. A com-
plete example is provided below.
Type approval name
DAILY 35S17H CCS W
● DAILY ‒ Vehicle name
● 35 ‒ Gross mass - GVW (no/10 = weight in t)
35 3.5 t
55 5.5 t
● S ‒ Rear wheels
S Single rear wheels
● 17 ‒ Engine power (no. x 10 = power in HP)
15 146 HP
17 170 HP
● H ‒ Engine type
H Euro VI Engine (combined with engine power codes 17)
E3 Euro III Engine (combined with engine power codes 15)
● CCS ‒ Version
– Cab version
D Dual cab (6+1)
CCS Cowl (short)
CA Cut Away
● W ‒ 4x4
1.14 IDENTIFICATIONS
Logos, identification tradenames and nameplates must not be modified, displaced or removed since the original design appearance
of the vehicle must be safeguarded.
The application of trademarks relating to the transformation or outfitting must be authorised. They must not be applied near to the
IVECO tradenames or logos.
In the event of cowl vehicles, the positioning of the IVECO logo on the engine bonnet must be done only after final paint spraying
and must respect the measurements indicated qualitatively in the following figure.
