DAILY MCA2014 4x4 ‒ BODYBUILDER INSTRUCTIONS
POWER TAKE-OFFS
4.6 PTO MANAGEMENT
13
– Printed 603.95.994 – 1 Ed. - Base 05/2015
After-sales PTO installation
If an after-sales PTO is to be installed, then it is necessary to check the following:
● that the vehicle is equipped with the Cruise Control opt.;
● obtain approval for the intervention from IVECO and any specific instructions that may be required.
Note
The after-sales installation of a PTO means, once installation is complete, referring to IVECO Assistance Service to update the ECU
software through the teleservice.
PTO management on gearbox
Note
For instructions on how to engage and disengage the PTO on the gearbox, in addition to its “stationary” or “not stationary” config-
uration, please consult the Use and Maintenance Manual.
▶ For safety reasons, when the non-stationary PTO is engaged, gear changes are not possible and
the vehicle should not exceed a speed of 20 km/h.
▶ It is necessary to switch off the PTO when a torque withdrawal is not in progress.
▶ The PTO must be disengaged before turning off the engine using the bodybuilder connector. In
any case, the engine cannot be restarted from the connector while the PTO is still connected.
PTO management on transfer box
The engagement and disengagement of the power take-off are controlled by a solenoid valve.
Engagement:
● stop the vehicle and maintain the engine at idle speed;
● check that the lever of the half gears of the reduction unit (B) and of the gearbox gears are in neutral and that the handbrake
is engaged;
227329
Figure 9
● fully depress the clutch pedal;
● press and release the push-button 1 in Figure 8, which controls engagement of the PTO on the reduction unit;
