Iveco DAILY 4x4 Body Builder Instructions

22
DAILY MCA2014 4x4 ‒ BODYBUILDER INSTRUCTIONS
CHASSIS INTERVENTIONS
2.12 MODIFICATIONS TO THE HEATING/CONDITIONING PLANT
– Printed 603.95.994 – 1 Ed. - Base 05/2015
204649
Figure 7
1. Main heater
2. Optional supplementary heater
3. Solenoid valve
4. Additional heater installed by body builder
A. Solenoid valve (3) open
B. Solenoid valve (3) closed
N.B. Heaters (2) and (4) may even be present on their own.
