Iveco DAILY 4x4 Body Builder Instructions

6
DAILY MCA2014 4x4 ‒ BODYBUILDER INSTRUCTIONS
APPLICATIONS OF SUPERSTRUCTURES
3.1 CONSTRUCTION OF THE COUNTER CHASSIS
– Printed 603.95.994 – 1 Ed. - Base 05/2015
Resistance modulus W
x
[cm
3
]
Recommended C profile
[mm]
27 ≤ W ≤ 30 80 X 60 X 7 100 X 50 X 5
31 ≤ W ≤ 33 80 X 60 X 8 100 X 60 X 5
34 ≤ W ≤ 36 100 X 60 X 6
37 ≤ W ≤ 41 100 X 60 X 7
42 ≤ W ≤ 45 80 X 80 X 8 100 X 60 X 8
46 ≤ W ≤ 52 120 X 60 X 6 120 X 60 X 7
53 ≤ W ≤ 58 120 X 60 X 8
59 ≤ W ≤ 65 140 X 60 X 7 120 X 70 X 7
66 ≤ W ≤ 72 140 X 60 X 8 120 X 80 X 8
73 ≤ W≤ 79 160 X 60 X 7
80 ≤ W≤ 88 180 X 60 X 8
89 ≤ W≤ 93 160 X 70 X 7 180 X 60 X 7 140 X 80 X 8
94 ≤ W≤ 104 180 X 60 X 8
105 ≤ W≤ 122 200 X 80 X 6 200 X 60 X 8 180 X 70 X 7
123 ≤ W≤ 126 220 X 60 X 7
127 ≤ W≤ 141 220 X 60 X 8
142 ≤ W≤ 160 200 X 80 X 8 240 X 60 X 8
161 ≤ W≤ 178 220 X 80 X 8 240 X 70 X 8
179 ≤ W≤ 201 250 X 80 X 7 260 X 70 X 8
202 ≤ W≤ 220 250 X 80 X 8 260 X 80 X 8
221 ≤ W≤ 224 220 X 80 X 8 280 X 70 X 8
225 ≤ W≤ 245 250 X 100 X 8 280 X 80 X 8
246 ≤ W ≤ 286 280 X 100 X 8
290 ≤ W ≤ 316 300 X 80 X 8
316 ≤ W ≤ 380 340 X 100 X 8
440 380 X 100 X 8
480 400 X 100 X 8
While the form of resistance represents a decisive value for the stress of the material, the moment of inertia is important mainly
for the flexural hardness and for the quota of the bending moment to be taken, depending on the connection used.
Counter-chassis dimension
In case of elastic connection between chassis and counter-chassis the bending moment M
f
must be subdivided proportionately
between chassis and counter-chassis at the moments of inertia of the sections:
