C
Only the first 3 digits (###) of a value are displayed on the screen. Values greater than
1000 are marked with "k". Example: 003k = 3000
Address format RD/WR Unit Note Adjustment range Default
509 SHORT RD/WR - Voltage connection diagram 0..8
2)
0
510 SHORT RD/WR - Current connection diagram 0..8 0
511 SHORT RD/WR - Relevant voltage for
THD and FFT 0, 1 0
The THD and FFT voltages can be displayed as L-N or L-L values. 0=LN, 1=LL
512 SHORT RD/WR - Year 0..99
513 SHORT RD/WR - Month 0..12
514 SHORT RD/WR - Day 0..31
515 SHORT RD/WR - Hour 0..24
516 SHORT RD/WR - Minute 0..59
517 SHORT RD/WR - Second 0..59
600 UINT RD/WR - Overrange 0..0xFFFFFFFF
750 SHORT RD - Software release
754 SERNR RD - Serial number
756 SERNR RD - Production no.
746 SHORT RD/WR s Period of time after which the
backlight will switch to standby 60 .. 9999 900
747 SHORT RD/WR s Brightness of the standby backlight 0 .. 9 0
