SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-4 31217162
High Drive Speed Cutout Height 70 in (1.78 m) 70 in (1.78 m) 80 in (2.03 m) 80 in (2.03 m)
Platform Lift Up Time (Rated Load) 24 - 32 sec 29 - 37 sec 32 - 40 sec 36 - 44 sec
Platform Lift Down Time (Rated Load) 29 - 37 sec 29 - 37 sec 32 - 40 sec 32 - 40 sec
Hydraulic Pressures
Main Relief
Steer Relief (Right)
Steer Relief (Left)
Lift Relief
3800 psi
2500 psi
1900 psi
2750 psi
2700 psi
2500 psi
1900 psi
--
3800 psi
2500 psi
1900 psi
2750 psi
2750 psi
2500 psi
1900 psi
--
Electrical System Voltage 12V 48V 12V 48V
Ground Clearance 9.5 in (24.1 cm) 9.5 in (24.1 cm) 9.5 in (24.1 cm) 9.5 in (24.1 cm)
Breakover Angle 30° (57.7%) 30° (57.7%) 30° (57.7%) 30° (57.7%)
Electronic Arm Guards Pause Height (CE Only) 90 in 90 in 105 in 105 in
