SECTION 3 - MACHINE CONTROLS, INDICATORS, AND MACHINE OPERATION
31217162 3-5
3.6 GROUND CONTROL STATION
RT Machines
1. Emergency Stop Switch
2. Overload Indicator (LSS)
3. Lift/Lower Switch
4. Display Gauge
5. Engine Start Switch
6. Ground/Platform/OFF Key Selector Switch
OAD02030
1
2
3
4
5
6
