JLG RT3369 - ERT Machines Ground Control Station

SECTION 3 - MACHINE CONTROLS, INDICATORS, AND MACHINE OPERATION
3-6 31217162
ERT Machines
1. Emergency Stop Switch
2. Overload Indicator (LSS)
3. Lift/Lower Switch
4. Display Gauge
5. Not Used
6. Ground/Platform/OFF Key Selector Switch
7. Genset Start Switch (If Equipped)
8. Genset Indicator (If Equipped)
1
2
3
4
7
6
8
OAD02050
