SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
31217162 6-5
Dimensions Maximum Allowable Operating Slope
Dimension Measurement
Stowed Height
RT2669, ERT2669
RT3369, ERT3369
96.7 in (2456 mm)
102.91 in (2614 mm)
Machine Length
Extension Retracted
Extension Deployed
139 in (3530 mm)
170.9 in (4340 mm)
Machine Width 69.3 in (1760 mm)
Wheelbase 81.3 in (2065 mm)
Model
Lift Up and Drive prevented
when elevated and tilted Front
to Back beyond the following
limits:
Lift Up and Drive prevented
when elevated and tilted Side to
Side beyond the following
limits:
RT2669,
ERT2669
3°
4.0° at 0% - 55% Capacity
3.0° at 56% - 75% Capacity
2.5° at 76% - 100% Capacity
RT3369,
ERT3369
3°
3.5° at 0% - 35% Capacity
3.0° at 36% - 55% Capacity
2.5° at 56% - 100% Capacity
