SECTION 3 - MACHINE CONTROLS, INDICATORS, AND MACHINE OPERATION
31217162 3-7
Ground Controls
DO NOT OPERATE FROM GROUND CONTROL STATION WITH PERSONNEL IN THE PLAT-
FORM EXCEPT IN AN EMERGENCY.
NOTE: When the machine is shut down for overnight parking or battery
charging, the emergency stop and power selector switches must
be positioned to OFF to prevent draining the batteries.
1. Emergency Stop Switch - A two-position, red, mushroom-
shaped ignition/emergency stop switch, when positioned to
ON with the power selector switch positioned to ground,
furnishes operating power to the ground control station. In
addition, the switch can be used to turn off power to the
function controls in the event of an emergency. Power is
turned on by pulling the switch out (on), and is turned off by
pushing the switch in (off).
ALWAYS POSITION EMERGENCY STOP SWITCH TO "OFF" POSITION (PUSHED IN) WHEN
MACHINE IS NOT IN USE.
2. Overload Indicator (LSS) - The Overload Indicator indicates
when the platform has been overloaded. An audible alarm
will also signal when the platform is overloaded.
NOTE: If the Overload Indicator is illuminated, further elevation will be
prevented. Reduce the weight in the platform so as to not exceed
the rated workload indicated on the capacity decal, then the
controls will work again.
3. Lift/Lower Switch - A two position momentary contact Lift/
Lower control switch raises and lowers the platform when
positioned to up or down.
4. Display Gauge -
• RT Machines: Displays the number of hours the machine
has been operated, fuel status, glow plug status, and any
active DTCs.
• ERT Machines: Displays the number of hours the machine
has been operated, current battery charge, battery tem-
perature, battery charge status (if plugged in), and any
active DTCs.
NOTE: Refer to Display Gauge on page 3-9 for more information.
