SECTION 3 - MACHINE CONTROLS, INDICATORS, AND MACHINE OPERATION
3-22 31217162
18. QuikLevel Advanced Status (If Equipped) -
• Rear Axle Extend:
• Rear Axle Retract:
• Rear Axle Aligned:
• Rear Axle Not Aligned:
• Drive at Height Allowed:
• Drive at Height Not Allowed:
• Speed Restricted (Low Speed): When
rear axle and chassis are not aligned,
drive speed is restricted.
19. Glow Plug (Not Shown) - When diesel
engine-powered machines are turned on,
the glow plug indicator will illuminate on
the display, regardless of engine or ambient
temperature. Do not start the engine until
the glow plug indicator light disappears.
3.9 PLATFORM CONTROL INDICATOR DISPLAY
Navigating the Display
1. At machine start up the machine brand logo will be dis-
played briefly, followed by the manual/lanyard reminder and
home screens.
