SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-8 31217162
Engine
Kubota Diesel (D1305-E4B)
Kubota Dual Fuel (WG972-GL-E4)
Emissions CARB, EPA Tier 4 Final, EU Stage V, China III
Fuel Type
Diesel:
- Low Sulfur (<500 ppm)
- Ultra Low Sulfur (15 ppm) (Required to meet
EPA Tier 4 Final, EU Stage V)
- up to 5% biodiesel
Number of Cylinders 3
Engine RPM Control Engine Control Unit (ECU)
Low RPM Set 1400 RPM
High RPM Set 2600 RPM
Alternator 40 Amp, 12 V, Belt-Driven
Battery 69 Amp-Hour, 700 Cold-Cranking Amps, 12 VDC
Fuel Consumption
Low RPM
High RPM
0.41 gal/hr (1.5 L/hr)
2.0 gal/hr (7.6 L/hr)
Displacement 1.261 L (77 cu. in.)
Gross Power 24.8 Hp (18.5 kW) @ 2600 RPM
Gross Torque 59.1 ft.lb. (80.1 Nm) @ 1700 RPM
Emissions CARB, EPA Phase 3
Fuel Type
Gasoline - 87 Octane minimum
- Ethanol/Gas Mix-10% maximum
- Methanol/Gas Mix-5% maximum
- LP (Liquid Petroleum)
Number of Cylinders 3
Engine RPM Control Engine Control Unit (ECU)
Low RPM Set 1400 RPM
High RPM Set 3500 RPM
Alternator 40 Amp, 12 V, Belt-Driven
Battery 69 Amp-Hour, 700 Cold-Cranking Amps, 12 VDC
Fuel Consumption
Low RPM
High RPM
Gas -
0.38 gal/hr (1.45 L/hr)
1.76 gal/hr (6.66 L/hr)
LP -
1.85 lb/hr (0.84 kg/hr)
9.3 lb/hr (4.23 kg/hr)
Displacement 0.962 L (58.7 cu. in)
Gross Power
Gas - 31.1 Hp (23.2 kW) @ 3600 RPM
LP - 29.5 Hp (22.0 kW) @ 3600 RPM
Gross Torque
Gas - 49.1 ft.lb. (66.6 Nm) @ 2400 RPM
LP - 48.8 ft.lb. (66.2 Nm) @ 1800 RPM
