JR Vigor CS User Manual

71
P-5
ASSEMBLY PROCESS – MAIN ROTOR HEAD
Socket Head Bolt, 3 x 15 mm
Socket Head Bolt, 3 x 15 mm (2 pcs)
...............2 pcs
Flat Head Screw, 2 x 10 mm
Flat Head Screw,
2 x 10 mm (2 pcs)
..........................2 pcs
Flange Bearing, 3 x 8 x 4 mm
Flange Bearing, 3 x 8 x 4 mm (4 pcs)
.........................4 pcs
Washout Link Pin
Washout Link Pin (2 pcs)
Washout Link
..........................2 pcs
CA Stopper Ring, 2 mm
CA Stopper Ring, 2mm (4 pcs)
...................................4 pcs
Washer, 3 x 4.5 x 0.4 mm
Washer, 3 x 4.5 x 0.4 mm (2 pcs)
Washout Base
Washout Arm
...................................2 pcs
Spacer, 3 x 5 x 1.8 mm
Spacer, 3 x 5 x 1.8 mm
(2 pcs)
..................................2 pcs
Steel Joint Ball
Steel Joint Ball (2 pcs)
...............................2 pcs
P-6
ASSEMBLY PROCESS – WASHOUT UNIT
Socket Head Bolt, 3 x 15 mm
Flat Head Screw, 2 x 8 mm
Flat Head Screw, 2 x 8 mm (4 pcs)
Steel Joint Ball
Steel Joint Ball (2 pcs)
Hex Nut, 2 mm (4 pcs)
Washer, 3 x 4.5 x 0.7 mm
(Thickness 0.7 mm)
Washer, 3 x 4.5 x 0.7 mm
(2 pcs)
(Thickness 0.7 mm)
Washer, 3 x 4.5 x 0.4 mm
(Thickness 0.4 mm)
........2 pcs
,.....................4 pcs
.......................4 pcs
...........................2 pcs
...........................2 pcs
...........................4 pcs
Hex Nut, 2 mm
Socket Head Bolt, 3 x 15 mm (2 pcs)
Washer, 3 x 4.5 x 0.4 mm (2 pcs)
(Thickness 0.4 mm)
4pcs
2pcs
Use Red
Threadlock
Red
Red
