GPS Navigator J-NAV500
12
1.4 Structure
The outside view of the display unit is shown below.
Figure 1-1
1.5 Equipment connections
Equipment connections are shown below.
GPS/DGPS receiver
(optional GPS 100 or DGPS 200)
12 VDC power/input Data I/O
(Power cable supplied)
To vessel ground
MODE
MENU
MOB
EVENT
GOTO
CONT
DIM
CLR
OFF
PWR
OFF
PUSH
Figure 1-2
MODE
MENU
MOB
EVENT
GOTO
CONT
DIM
CLR
OFF
PWR
OFF
PUSH
138
11721
46.5 104
197
46.5
124
74
28 96
UNIT : mm
WEIGHT : Less than 0.9kg
