GPS Navigator J-NAV500
47
4.15 Setting CDI range and Display Time Format
1. Display operations
Press in the [CDI] display mode.
To return to the [CDI] display mode, press .
2. Setting
(1) CDI range
The CDI range can be set as follows:
CDI RANGE:
0.1
(default),
0.3, 0.5 nm
(2) Display time format
Time can be displayed according to the following formats:
TIME DSP:
Local
(default)
UTC
(universal time)
4.16 Setting Plotting Information
1. Display operations
Press in the [PLOT] display mode.
To return to the [PLOT] display mode, press .
2. Setting
(1) Track storage interval
The navigator can be record the track line by time or distance. A total of 499 points can be
recorded and the memory is updated as new data is received.
TRACK INTERVAL
.5/1/3/5/10 minutes
(approx. 250 min to 83 hours)
.2/.5 nm
(approx. 100/250 nautical miles)
/off
(no data is stored) (default)
Setting a shorter storage interval, increases the accuracy of the track line, but uses up the total of
499 points in a shorter time. Longer intervals increase storage time but reduces accuracy of the
track line.
(2) Erasing track line
TRACK ERASE
This function cancels track line displayed in the [PLOT] display mode.
(3) Displaying track line
The track line display can be turned on and off.
TRACK LINE
on
(default)
/off
