PROC(Trigger)
Description
This message indicates that the trigger signal from the scanner is faulty.
If TXRX(Trigger) or TXRX(Data) is displayed, handle the error first.
A scanner equipment cable may be broken, the power terminal board circuit in the display system
may be faulty, or the radar processing circuit may be faulty.
Location of cause
o
Procedure
Power terminal board
circuit CBD-1702A in
the display system
x Check the CBD-1702A cable connection. J5002, J5003
x Replace the CBD-1702A.
CDC-1350 in the
display system
x Check the insertion of J4402 and J4003 on the radar processing
circuit CDC-1350.
x Replace the CDC-1350.
PROC(AZI)
Description
This message indicates that the rotation signal from the scanner is faulty.
If TXRX(AZI) or TXRX(Data) is displayed, handle the error first.
A scanner equipment cable may be broken, the power terminal board circuit in the display system
may be faulty, or the radar processing circuit may be faulty.
Location of cause
o
Procedure
Power terminal board
circuit CBD-1702A in
the display system
x Check the CBD-1702A cable connection. J5002, J5003
x Replace the CBD-1702A.
CDC-1350 in the
display system
x Check the insertion of J4402 and J4003 on the radar processing
circuit CDC-1350.
x Replace the CDC-1350.
