JRC JMA-5212-4/6 Service Manual

3-12
3.2.3. NDC-1460
PARTS LIST
RADAR PROCESS UNIT
NDC-1460/JMA-5200MK2
Fig.
No.
No. DESCRIPTION
DRAWING No.
JRC CODE
NOTE
1 Nameplate MPNN45149
2 Warning Label MPNN43252
3 Drip-proof Rubber MPPK30497A
4 Coaching Clip CS-4U BRBP05299 SHINAGAWA-SHOKO
5 Spacer BSB-308E BRBP06402 HIROSUGI
6 Bracket MTB382448
7 D-sub Cover MTB381018
8 Label MPNN40470
9 Panel MPBC40313
10 Chassis MPBX44552
11 Nylon Rivet FNRP㱢3x4.5 Black BRTG01052 KOYO-FASTENER
12 Power Supply Circuit CBD-1702A
13 Bracket1 (Connector) MTB382462
14 Bracket2 (Connector) MTB382463
15 Fiber Washer 3.2X6X0.5 White BRTG04252 KOSHIN
16 Spacer (L) MTL323365
17 Nut NO.4-40UNC Bs BNM2 BRTG09065 KOSHIN
18 Spacer (S) MTL323366
19 Heat sink MTC301546
20 Panel MPNN43566
21 Fuse
22 Radiator Sheet MTT308591
23 Connector
24 Rubber Washer MTT311607
25 Sems Screw NC3X12SUS BRTG03547 KOSHIN
26 Rubber Washer MTT311609
27 Gasket 1 MTT308585
28 Gasket 2 MTT308586
29 Label MPNN42981
30 Radar processing circuit CDC-1350
31 AIS Process Unit NQA-2155 Option
32 Plotter Control Unit NDB-34A Option
33 ATA Process Unit NCA-877A Option
34 Breaker SANKEN
35 Guard Handle THA-212-3 BRHD05338 TOCHIGIYA
36 Cover MTB381021
37 Sems Screw NB3X8Bs BSNB03008B
38 Spring Washer SW3 BSSW03000S
39 Washer LW3Bs BSLW03000W
MTZ303979
-1/1
40 Pan Head Machine Screw NK4X25Bs BSNK04025B
