JRC JMA-5212-4/6 Service Manual

3-2
3.1.2. Special Parts
Ԙ NKE-2103 (JMA-5212-4/6/4HS/6HS)
Parts No. Name Type Manufacturer Location Code
V101 Magnetron MAF1565N NJRC
Scanner
unit
5VHAA00102
A101/A102 Circulator FCX68R
Orient
Microwave
Scanner
unit
5AJIX00027
A103 Dummy NJC4002 NJRC
Scanner
unit
5ANDF00001
A104 Filter NJC9952 NJRC
Scanner
unit
5AWAX00002
A301 Diode limiter NJS6930 NJRC
Scanner
unit
5ATBT00006
ԙ NKE-2254 (JMA-5222-7/9)
Parts No. Name Type Manufacturer Location Code
V1 Magnetron M1568BS NJRC
Scanner
unit
5VMAA00106
A101/A102 Circulator NJC3901M NJRC
Scanner
unit
5AJBV00007
A103 Dummy NJC4002 NJRC
Scanner
unit
5ANDF00001
A104 Filter NJC9952 NJRC
Scanner
unit
5AWAX00002
A301 Diode limiter NJS6930 NJRC
Scanner
unit
5ATBT00006
3.1.3. NKE-2103 (JMA-5212-4/6/4HS/6HS)
Location Circuit Block Type Remarks
Scanner unit Motor with gear 7BDRD0048 DC brushless motor
Scanner unit Modulation circuit CME-363 Magnetron not included
Scanner unit Receiver NRG-610 CAE-529-1 included
Scanner unit Power circuit CBD-1783
Scanner unit Encoder CHT-71A
Scanner unit Motor control power circuit CBD-1779
Scanner unit Fan 7BFRD0002
Scanner unit Performance monitor NJU-85
