JRC JMA-5212-4/6 Service Manual

2-3
(Notes)
Ԙ A deicing mechanism (neck heater) is optional. "D" is suffixed to the model number
of a scanner unit with a deicing mechanism. Keep in mind that only power supply of
100-115 VAC, 50/60 Hz and single phase is applicable to the neck heater and that a
deicing mechanism cannot be installed in the NKE-2103.
ԙ A scanner unit and display system are indicated on the nameplate of the equipment
as follows:
SCANNER UNIT
DISPLAY UNIT
Ԛ The display system has a separate structure consisting of the following:
Display unit NWZ-164
Control unit NCM-866-E
The control unit NCM-866-E (IMO compliance) consists of the following:
Processor unit NDC-1460
Operation unit NCE-7699A

JRC JMA-5212-4/6 Specifications

General

Brand	JRC
Model	JMA-5212-4/6
Category	Marine Radar
Language	English
