JRC JMA-5212-4/6 Service Manual

3-5
9-4 Packin
g
MTT305919A
9-5 Swich Cove
r
MPPK00925A 㩷㩷
9-6 Cable Push Plate MTB366112 㩷㩷
9-7 Cable Clam
p
BRBP00009 㩷㩷
9-8 Cross-recessed Head Screw BSNK04010B 㩷 NK4X10Bs
9-9 Cross-recessed Head Screw BSNC04010B 㩷 NC4X10Bs
9-10 Cross-recessed Head Screw BSNB05010B 㩷 NB5X10Bs
10 Tranceiver Ass
y
. MDNZT5023 㩷 NZT-2103
10-1 Main Chassis MPBX44420 㩷㩷
10-2 Wave Guide Circuit MPAB31606 㩷㩷
10-2-1 CIR-Attachment MTB389799 㩷㩷
10-2-2 Recever Unit MDNRG5093 NRG-610 NRG-610
10-2-3 Diord Limite
r
5ATBT00006 㩷 NJS6930
10-2-4 Circulato
r
5AJIX00027 㩷 FCX68R
10-2-5 Filte
r
5AWAX00002 㩷 NJC-9952
10-2-6 Guide Plate
MT䌌326122
㩷㩷
10-2-7 Dumm
y
Load 5ANDF00001 㩷 NJC4002
10-2-8 S
p
ace
r
MTL318403 㩷㩷
10-2-9 MG-PIN MTL325492 㩷㩷
10-2-10 - 㩷 㩷㩷
10-2-11 Bolts BRTG07397 㩷 M4X12 SW SUS304
10-2-12 Cross-recessed Head Screw BRTG07156 㩷 M4X70 Bs
10-2-13 Cross-recessed Head Screw BSNC04010B 㩷 NC4X10Bs
10-2-14 S
p
rin
g
Washers BSSW04000S 㩷 SW4
10-2-15 Washers BSFW04000B 㩷 W4Bs
10-3 Modulator Unit MPBX44290 CME-363 㩷
10-4 Power Su
pp
l
y
Unit MPBX44291 CBD-1783 㩷
10-5 Motor Control PC MDBW10832 CBD-1779 CBD-1779
10-6 Ma
g
netron 5VMAA00102 5VMAA00102 MAF1565N
10-7 Resistors - 㩷 CFA-252
10-8 Filter PC - 㩷 CFR-234
10-9 Cove
r
MTB389805 㩷㩷
10-10 Nut Plate MTB388518 㩷㩷
10-11 Connection Plate MTB388903 㩷㩷
10-12 Motor Cove
r
MTB391765 㩷㩷
10-13 Cross-recessed Head Screw BSNB04012B 㩷 NB4X12Bs
10-14 Cross-recessed Head Screw BSNC04010B 㩷 NC4X10Bs
10-15 Cross-recessed Head Screw BSNC04016B 㩷 NC4X16Bs
10-16 Cross-recessed Head Screw BSNC03008B 㩷 NC3X8Bs
11 Encoder Plate MTB388510A 㩷㩷
12 Sta
y
MPDM30321 㩷㩷
13 Grand-Cable H-7ZCRD1504 㩷㩷
14 Shaft MTL325006 㩷㩷
15 Bolts MTL006545A 㩷 M8X35 Machinin
g
16 S
p
rin
g
Washers BRTG00747 㩷 SW8 SUS
17 Washers BRTG00224 㩷 W8
18 O-Rin
g
BRPK00027 㩷 P7
19 Clam
p
Gland MPTG30399 㩷㩷
20 Cove
r
BRTG01414 㩷㩷
21 Gasket MTT308695A 㩷㩷
