9-2
3) Interface
(1) Serial Transmission
Channel Specification Notes
DATA IN/OUT1 RS-422 Input or Output NMAE, IEC
DATA IN/OUT2 RS-422 Input or Output NMEA, IEC
DATA IN/OUT3 RS-422 Input or Output NMEA, IEC
DATA IN/OUT4 RS-422 Input or Output NMEA, IEC Daisy chain
RS-485 RS-485 Input NMEA, IEC
Output
(1-1) NMEA
 Specification: NMEA
 Version: Ver1.5, 2.1, 2.3, 4.0
 Bit rate: 4800, 9600,19200,38400bps
 Data bit: 8bit
 Parity: None
 Start bit: 1bit
 Stop bit: 1bit
 Output sentence ACK,CUR,DBK,DBS,DBT,DPT,GGA,GLL,GNS,HDG,HDM,HDT,MDA,MHU,MMB,
MTA,MTW,MWV,RMC,ROT,RPM,RSA,THS,VBW,VDR,VHW,VLW,VTG,VWR,VWT
,XDR,ZDA
 Output interval: 1s, 2s, 3s, 4s, 5s, 6s, 7s, 8s,9s, OFF
Note) Som combinations of output sentence, bit rate, and output intervals may not be possible.
(1-2) IEC
 Specification: IEC61162-1 ed.4
(2) Contact signal
Channel I/O Notes
CONTACT OUTPUT 200p/NM, 400p/NM
CONTACT INPUT ACK, Input of external dimmer
