4.5.6. Setting graph scale
The vertical axis and horizontal axis scale of the water temperature and water depth graphs can be set.
For detail screen, refer to page 2-2.
Horizontal axis setting
TIME: The maximum display time of the horizontal axis is set.
The time that can be set is 5 minutes, 10 minutes, 20 minutes, and 30 minutes.
Vertical axis setting
MAX: The maximum value of the display value is set.
MIN: The minimum value of the display value is set.
Procedure
1. Press the
key to display the main menu.
Water depth
2. Press the
key to select “DISPLAY,” “GRAPH SCALE,” and “DEPTH” in order.
3. Press the
key to enter “TIME,” “MAX,” or “MIN,” and press the key.
Water temperature
2. Press the
key to select “DISPLAY,” “GRAPH SCALE”, and “WATER TEMP” in order.
3. Press the
key to enter “TIME,” “MAX,” or “MIN,” and press the key.
4.5.7. Registering user display
From among the screens registered in the display screen, the user display assigned to the
key
can be registered.
Procedure
1. Press the
key to display the main menu.
2. Press the
key to select “1.DISPLAY” and “USER DISPLAY” in order.
3. Press the
key to select the screens to be registered from “DISPLAY1” to “DISPLAY6,” and
press the
key.
