JRC NWZ-4610 - Removing the Display Unit by Flash Mounting

6-8
6.2.4. Removing the display unit by flash mounting
Use the following procedure to remove the display unit.
(1) Insert a hexagonal wrench into the holes (2) at the bottom of the front panel.
(2) Remove the front panel by pressing down the hexagonal wrench.
Mounting wall
Front panel
Prepare a board to protect
the wall from being
damaged.
Hexagonal wrench
Recommended size: 3 mm
Press down
