1.3. Components
The standard equipment and options are shown in the tables below.
1.3.1. Standard equipment
No. Description Model No. CODE QTY Remarks
1.1
DISPLAY NWZ-4610 NWZ-4610 1 Main Body
1.2
DATA POWER CABLE CFQ-5766A CFQ5766A 1
14 cores 2 m/ With Fuse holder
data, power, contact
1.3
FUSE MF60NR 250V 1 5ZFGD00205 2 Display unit 1A fuse
1.4
FRONT PANEL MTV305018A MTV305018A 1
1.5
BASE KITS MPBX47065 MPBX47065 1
Base
Knob Bolt
Gear Washer
Knob Washer
1.6
MODEL
IDENTIFICATION
PLATE
MPNN47524A MPNN47524A 1 For Rear
1.7
PRODUCT
NAMEPLATE
MPNN47529A MPNN47529A 1 For Front
1.8
Flush Mounting
Drawing
- - 1 For Flush Mount
2
QUICK REFERENCE 7ZPNA4352 7ZPNA4352 1 English/Japanese
1.3.2. Options
No. Description Model No. CODE QTY Remarks
1
AC POWER
RECTIFIER
NBD-577C NBD-577C 1 AC100/220V input
24V output
2
DATA POWER CABLE CFQ-5766D CFQ5766D 1 14 cores 10 m/ With Fuse holder
data, power, contact
CFQ-5766F CFQ5766F 1 14 cores 20 m/ With Fuse holder
data, power, contact
3
DATA CABLE CFQ-5767 CFQ5767 1 4 cores/3 m data
6-pin connector data line only
4
DATA CABLE CFQ-5768 CFQ5768 1 6 cores-14 cores/3 m daisy chain
5
DATA CABLE CFQ-5769 CFQ5769 1 For RS-485 4 cores/3 m
6
T-SHAPED
CONNECTOR
AA-040404-MMM-TL 5JCDX00071 1 For CFQ-5769 RS-485
7
JUNCTION BOX CQD-10 CQD-10A 1 12 terminals
8
DIMMER UNIT NCM-227 NCM-227 1 External dimmer unit
9
L-TYPE ADAPTER CFQ-9184 CFQ9184 1
10
INSTRUCTION
MANUAL
7ZPNA4284 7ZPNA4284 1 English
7ZPNA4283 7ZPNA4283 1 Japanese
