4.9.6. Setting a contact port
4.9.6.1. Setting a contact input port
A contact input port can be set to the following input.
1) DIMMER: Use this option when connecting an external dimmer unit.
2) ACK: Alarm ACK is input from an external unit.
To use an external dimmer unit, the dimmer unit must be set to “EXT DIMMER”. See “4.9.3 Selecting a
dimmer unit” for the setting method.
Procedure
1. Refer to “4.9.1 Changing to a maintenance mode” to display the maintenance menu.
2. Select “INTERFACE”, “DATA I/O” and “CONTACT INPUT” in this order by using
.
3. Select an item to be input by using
and press .
4.9.6.2. Setting a contact output port
A contact output port can be set to the 400Pluse/NM or 200Pluse/NM input.
Procedure
1. Refer to “4.9.1 Changing to a maintenance mode” to display the maintenance menu.
2. Select “INTERFACE”, “DATA I/O” and “CONTACT OUTPUT” in this order by using
.
3. Select an item to be input by using
and press .
