6-16
[To Group Dimmer Control]
The following shows an example of grouping 10 units (maximum number of connections) into 3 units, 3
units, and 4 units.
Dimmer group: 01
Dimmer: Key
Dimmer group: 02
Dimmer: External dimmer
Dimmer group: 03
Dimmer: Key
RS485ID:06 RS485ID:05
RS485ID:02
SOG
12.3 kn
SOG
12.3 kn
SOG
12.3 kn
RS485ID:01 RS485ID:03
RS485ID:04
RS485ID:09 RS485ID:08 RS485ID:07
SOG
12.3 kn
SOG
12.3 kn
SOG
12.3 kn
RS485ID:10
SOG
12.3 kn
SOG
12.3 kn
SOG
12.3 kn
SOG
12.3 kn
NCM-227
Dimmer unit
DIMMER
Key operation
Key operation
Volume control
CFQ-5769: 3 m
