Switch/display Description
Customization button A selected function can be allocated to and registered with this button.
This button has been initially set to the "prohibition of thread trimming".
Refer to "4-2-6. List of pattern functions" p. 44.
Customization button A selected function can be allocated to and registered with this button.
This button has been initially set to the "feed timing".
Refer to "4-2-6. List of pattern functions" p. 44.
Multi-layer stitching
button
The multi-layer stitching setting screen is displayed by keeping this button
held pressed for one second.
Refer to "4-2-5. Editing the sewing patterns" p. 42.
→
This button is displayed when multi-layer stitching is selected.
Number of stitches This button is used for displaying the number of stitches of constant-dimen-
sion sewing or the number of stitches registered for each step of polygo-
nal-shape stitching.
→
This button is displayed when constant-dimension sewing or polygo-
nal-shape stitching is selected.
Display of the
number of steps of
a polygonal-shape
stitching pattern
This button is displayed when constant-dimension sewing or polygonal-shape
stitching is selected (1 to 20).
→
This button is displayed when polygonal-shape stitching is selected.
* Only in the case the maintenance personnel mode is selected.
– 32 –
