– 23 –
The sewing speed is displayed in section A
on the panel. (Example of display : 4,000 sti/
min)
[How to change]
1) Display the sewing speed entry screen by
pressing .
3-8. Changing the sewing speed
2) Change the sewing speed as desired by
pressing ten keys .
3) Conrm your entry by pressing .
Then, the sewing screen is displayed.
Stitch length is displayed in section A on the
panel. (Example of display : 2.50 mm)
[How to adjust]
1) Display the stitch pitch entry screen by
pressing .
3-7. Adjusting the stitch length
2) The value displayed is changed by pressing
. (In increments of 0.05 mm ;
Input range : -5.00 to 5.00)
3) Conrm your entry by pressing .
Then, the sewing screen is displayed.
1. There may be the cases where the feed amount of the operation panel and the actual sewing
pitch are different from each other in case of the use in the state other than the standard
delivery or material used. Compensate the pitch in accordance with the sewing product.
2. Be aware that interference between the throat plate and feed dog can occur depending on
the gauge used. Be sure to check the clearance in the gauge to be used. (The clearance
must be 0.5 mm or more.)
3. When you have changed the stitch length, feed dog height or feed timing, run the sewing
machine at a low speed to make sure that the gauge does not interfere with the changed
part.
A
A
