– 78 –
5-4. Changing the feed locus
Feed locus
(shape)
"Image g-
ure"
Name Characteristics (movement of the feed dog) Stitch length and sewing speed
S
(Standard)
Standard smooth elliptical locus
0 to 4.00 mm : 5,000 sti/min
(H type : 4,500 sti/min)
4.05 to 5.00 mm : 4,000 sti/min
A
During ascending, the feed dog goes straight
up and moves in parallel in terms of longitudi-
nal direction.
0 to 5.00 mm : 4,000 sti/min
C
When the needle penetrates the material, the
feed dog sinks straight down. As a result, the
bent-needle problem rarely occurs.
0 to 5.00 mm : 4,000 sti/min
B
The feed dog goes straight up and sinks
straight down.
Since it sinks straight down during descending,
the bent-needle problem rarely occurs.
With this type of locus, the stitch length does
not change largely even when the feed dog
height is changed.
0 to 5.00 mm : 2,500 sti/min
The feed locus can be changed according to
the item to be sewn.
[How to change]
1) Display the sewing data edit screen by
pressing ❶.
Or, display "S048 Feed mode" by pressing
❷.
2) Display "S048 Feed mode" by pressing
❸.
3) Change the feed locus.
* Refer to the following for the types of feed
locus.
4) Conrm your entry by pressing ❹.
5) Display the sewing screen by pressing
❺.
❸
❸
❹
❶ ❷
