– 24 –
3-9. LED hand light
WARNING :
In order to protect against personal injury due to unexpected start of the sewing machine, never
bring hands near the needle entry area or place foot on the pedal during the adjustment of intensity
of the LED.
* This LED is intended to improve operability
of the sewing machine and is not intended for
maintenance.
The sewing machine is provided as standard with an
LED light which illuminates the needle entry area.
Intensity adjustment and turn-off of the light is car-
ried out by pressing switch . Every time the switch
is pressed, the light is adjusted in intensity in ve
steps and is turned off in turn.
[Change of intensity]
1
...... 4
5
1
Bright
...... Dim
O
ff
Bright
In this way, every time the switch is pressed, the
hand lamp status is changed in repetition.
3-10. Reverse feed stitching
[One-touch type reverse feed stitching mecha-
nism]
The one-touch type reverse feed switch is
pressed, the machine performs reverse feed stitch-
ing.
The machine resumes normal feed stitching the
moment the switch lever is released.
[Reverse feed stitching by means of the reverse
feed lever]
Length of the seam sewn by feeding the material in
the normal or reverse direction of feed can be con-
trolled by operating reverse feed lever .
[Adjusting the position of one-touch type reverse
feed switch]
One-touch type reverse feed switch can be used
at two different positions by turning it. (Fig. 1)
Fig. 1
