JUKI DDL-9000C-S Series User Manual

Data name
Picto-
graph
Extension Description of data
Sewing data
DDL00XXX.EPD
(XXX:001~999)
Data format of sewing shapes and number of
stitches created on the sewing machine. This
format is specic to the DDL-9000C.
Custom pitch data
VD00XXX.VDT
(XXX:001~999)
It is the data of needle entry point created with
PM-1, and the data format that can be operat-
ed in common between JUKI sewing machines.
Condensation custom data
VD00XXX.VDT
(XXX:001~999)
It is the data of needle entry point created with
PM-1, and the data format that can be operat-
ed in common between JUKI sewing machines.
Memory switch data DDL00 XXX .MSW
(XXX:001
～
999)
Memory switch data
Panel program data DDL00 XXX .MSP
(XXX:001
～
999)
All data maintained by the sewing machine
Panel program data SP RVL(6 digits) .HED
SP RVL(6 digits) .P00
Panel program data
Main program data MT RVL(6 digits) .HED
MT RVL(6 digits).P01
Main program data
(When communication data is other than the program data,)
1. While data is being written, the screen of
such a situation is displayed.
2. After writing of data is completed, the
current screen returns to the selection
screen of communication data No.
* When the screen giving you instructions
to turn off the sewing machine has been
displayed after completion of such a writ-
ing of data, turn off the sewing machine.
(When communication data is the program data,)
1. While a program is being written, the
screen of such a situation is displayed.
2. After such a writing of a program is com-
pleted, the screen giving you instructions
to turn off the sewing machine is dis-
played. Turn off then machine.
3. When you turn on the sewing machine
again, the written program is executed.
3)
List of communication data formats
– 85 –
