Upper and lower link arm setscrew
Upper and lower
link arm
Feed dog
It is the height of a feed dog from the surface of
a throat plate.
* Remove the presser and do not apply the
presser pressure.
(7) Various origin adjustments
WARNING :
Be sure to turn the power OFF before the following work in order to prevent personal injury due to
unintentional starting of the sewing machine.
Standard adjustment
5) Vertical feed link adjustment
– 32 –
