No. Item Setting range Unit
Initial value
SMS SSH FMS FSH
SMS CE
SSH CS FMS CE FSH CE
U070
Presser-foot 2nd step lifting height
Maximum height of presser foot at the 2nd step of its lifting
operation when the back part of pedal is depressed. (When the
back part of pedal is depressed until the thread trimming position is
reached after the presser foot comes down after thread trimming)
8.5 to 13.5 mm 8.5 8.5 8.5 8.5 8.5 8.5 8.5 8.5
U087
Pedal acceleration characteristic
0: Standard / -1 to -10: Square / 1 to 10: Square root
−10 to 10 - 0 0 0 0 0 0 0 0
U090
Initial-start upper-position stopping function
0: The sewing machine stops with its needle up after checking
the panel.
1: The machine automatically stops with its needle up.
0 to 1 - 1 1 1 1 1 1 1 1
U096
Maximum sewing speed
The initial value differs with the machine head.
150 to Max sti/min 4000 4000 4000 4000 4000 4000 4000 4000
U120
Main shaft reference angle correction
The main shaft reference signal angle (0 degree) is corrected
with the value set using this memory switch.
−60 to 60
Degree
0 0 0 0 0 0 0 0
U121
Upper stop position angle correction
The position at which the sewing machine stops with its needle
down is corrected.
−15 to 15
Degree
0 0 0 0 0 0 0 0
U122
Lower stop position angle correction
The position at which the sewing machine stops with its needle
up is corrected.
−15 to 15
Degree
0 0 0 0 0 0 0 0
U182
Sewing counter stopping function
0: The sewing machine does not stop even when the sewing
counter completes counting.
1: When the counter completes counting, the sewing machine
start after thread trimming is prohibited.
* Note that the prohibition function is disabled in the case the
initial value of counter is 0 (zero).
0 to 1 - 0 0 0 0 0 0 0 0
U183
Number of times of thread trimming for sewing counter
1 to 20 - 1 1 1 1 1 1 1 1
– 108 –
