No. Item Setting range Unit
Initial value
SMS SSH FMS FSH
SMS CE
SSH CS FMS CE FSH CE
U052
Correction of turning-OFF of reverse feed stitching (at start)
−50 to 50
Degree
0 0 0 0 0 0 0 0
U053
Correction of turning-OFF of reverse feed stitching (at end)
−50 to 50
Degree
0 0 0 0 0 0 0 0
U055
Presser foot lift after thread trimming
The initial value differs with the machine head.
0: No lift / 1: Lift
0 to 1 - 1 1 1 1 1 1 1 1
U056
Reverse-rotation needle-up after thread trimming
The initial value differs with the machine head.
0: Reverse-rotation needle-up is not performed /
1: Reverse-rotation needle-up is performed
0 to 1 - 0 0 0 0 0 0 0 0
U057
Function for lowering the feed dog during thread trimming
The presser foot height is xed at 0 (zero) during thread trimming.
0: OFF / 1: ON
0 to 1 - 1 1 1 1 1 1 1 1
U059
Selection of revere feed stitching (at start) operation
0: Manual / 1: Automatic
0 to 1 - 1 1 1 1 1 1 1 1
U060
Stop after reverse feed stitching (at start)
The stop function stops the sewing machine temporarily
regardless of the operating status of the pedal.
0: OFF / 1: ON
0 to 1 - 0 0 0 0 0 0 0 0
U064
Sewing speed at the start of reverse feed stitching (at end)
150 to 1000 sti/min 500 500 500 500 500 500 500 500
U068
Presser foot lifting operation changeover
The presser foot lifting operation when depressing the back part
of pedal is changed over.
0: 2-step operation / 1: Manual operation depending on the pedal
stroke when the back part of pedal is depressed
0 to 1 - 0 0 0 0 0 0 0 0
U069
Presser-foot 1st step lifting height
Maximum height of presser foot at the 1st step of its lifting
operation when the back part of pedal is depressed.
0.1 to 8.5 mm 5 5 5 5 5 5 5 5
– 107 –
