List of input functions
Abbreviation
Function item Remark
0 NOP No function (Standard setting)
1 HS Needle up/down correction stitching
Every time the switch is pressed, normal feed
stitching by half stitch is performed.
2 BHS Reverse-feed correction stitching
Reverse feed stitching is performed at low speed
while the switch is held pressing.
3 EBT
Function for cancelling reverse-feed
stitching (at end) once
By depressing the back part of the pedal after
pressing the switch, operation of reverse feed
stitching is canceled once.
4 TSW Thread trimmer function
This function is actuated as the thread trimming
switch.
5 FL Presser lifter function This function is actuated as the foot lifter switch.
6 OHS 1-stitch correction stitching
Every time the switch is pressed, one stitch
stitching operation is executed.
7 SEBT
Function for cancelling reverse-feed
stitching (at start) (at end)
By operating the optional switch, ineffective/
effective can be alternately changed over.
8 LINH
Function for prohibiting depress on
the front part of pedal
Rotation by pedal is prohibited.
9 TINH
Thread trimmer output prohibition
function
Output of thread trimming is prohibited.
10 LSSW Low-speed command input
This function works as low speed switch for
standing sewing machine.
11 HSSW High-speed command input
This function works as high speed switch for
standing sewing machine.
12 USW Needle lifter function
UP stop motion is performed when switch is
pressed during DOWN stop.
13 BT Reverse-feed stitching switch input
Reverse feed stitching is output as long as the
switch is held pressed.
14 SOFT Soft-start switch input
The speed of stitch is limited to the predetermined
soft-start speed as long as the switch is held
pressed.
15 OSSW One-shot speed command switch input
This function works as one-shot speed command
as long as the switch is pressed.
16 BKOS
Reverse-feed one-shot speed
command switch input
Reverse feed stitching is performed in accordance
with the one-shot speed command as long as the
switch is held pressed.
17 SFSW Safety switch input Rotation is prohibited.
18 AUBT
Automatic reverse-feed stitching
cancellation/addition switch
Every time the switch is pressed, reverse feed
stitching at sewing start or reverse feed stitching
at sewing end is cancelled or added.
19 CUNT Sewing counter input
Every time the switch is pressed, the sewing
counter value is increased.
20 OTSW One-touch change-over switch
This function changes the settings of a pattern
stitch mode every time the SW (switch) is pressed.
5. Setting of an input function
Select the function allocated to an input signal from an input function list.
Select a function item B by pressing the ❶, and enter the function item by pressing the ❷.
Display a selection of HIGH or LOW by pressing the ❶, and move to active level selection F of
output to switch between LOW and HIGH.
Afterthesettingiscompleted,xthesetcontentsbypressingthe ❻.
(Caution) When you turn off the sewing machine without pressing the ❻, the set contents are
not reected.
– 128 –
