JUKI LK-1900B series Engineer's Manual

– 111 –
No.
6 7 8 9 10 11
Work clamp
foot
13548151(asm.) 13542451 (asm.) 13571955 (asm.) 13561360 (asm.)
40.5
27
35
32.6
5
10
22
40
4.5
32.8
5.6
12
24.1
50
23
2
20
54
Feed plate 13548003 13554803 14116602 14116503 14116909 14116701
(With knurl) (With knurl) (With knurl) (Without knurl) (Without knurl) (Without knurl)
37.3
25
18.5
15
27.4
5.4
24
17.5
15
25
40
5.6
23
2.4
24
22
Sewing spec-
ication
S, B H / W S, B F, B F F
* Finger guard 13548300 13533104 13573407
Remarks Optional Standard acces-
sory for H type
(Heavy-weight
material) and W
type(Double-ca-
pacity hook)
machine head.
Optional Accessory part for F (foundation)
type. (Depends on the destination)
Optional
No.
12 13 14 15 16
Work clamp
foot
14137509 (right)
14137608 (left)
40021871 (right)
40021872 (left)
40021874 (right)
40021875 (left)
40021877 (right)
40021878 (left)
40021880 (right)
40021881 (left)
4
33
23.5
60
13.6
9 28
41
14
23
12
29
45
ø12
10
30
45
ø10
14 28
45
ø14
Feed plate 14137707 40021873 40021876 40021879 40021882
(Without knurl) (With knurl) (With knurl) (With knurl) (With knurl)
30
16.6
50
14.4
9.4
ø12.4 ø10.4 ø14.4
Sewing spec-
ication
F, B S * S * S * S *
* Finger guard 14135305 13533104
Remarks Optional Optional Optional Optional Optional
*Installangerguardsuitableforeachworkclampfootwhenreplacingtheworkclampfoot.
* The work clamp foot No. 12 (optional) should be used for the standard patterns Nos. 41 to 46 (lengthwise
bar-tacking) of "8.-(3) Table of standard patterns".
*WhenusingtheNo.13to16atsewingspecicationB,usethefeedplatedescribedbelow.
• No.13 : 40158195
• No.14 to 16 : 40158196
