Installing an ACX1000 and ACX1100 Management Ethernet Cable
To install a serial cable connected to a management device:
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the
ESD points on the chassis.
2. Plug one end of the replacement cable into the appropriate MGMT port.
3. Plug the other end of the cable into the network device.
See Also Removing an ACX1000 or ACX1100 Management Ethernet Cable on page 114•
• Management Port Connector Pinout Information for ACX Series Routers on page 73
Related
Documentation
Management Port Connector Pinout Information for ACX Series Routers on page 73•
Replacing an ACX1000 or ACX1100 Fiber-Optic Cable
To replace a fiber-optic cable:
1.
Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 115
2.
Connecting an ACX1000 or ACX1100 Fiber-Optic Cable on page 116
Disconnecting an ACX1000 or ACX1100 Fiber-Optic Cable
ACX Series routers have field-replaceable unit (FRU) optical transceivers to which you
can connect fiber-optic cables.
Before you begin disconnecting a fiber-optic cable from an optical transceiver installed
in an ACX Series router, ensure that you have taken the necessary precautions for safe
handling of lasers (see “Laser and LED Safety Guidelines and Warnings” on page 158).
Ensure that you have the following parts and tools available:
•
A rubber safety cap to cover the transceiver
•
A rubber safety cap to cover the fiber-optic cable connector
115Copyright © 2017, Juniper Networks, Inc.
Chapter 22: Replacing Chassis Components
