LEDs on ACX1000 and ACX1100 Routers
Unless otherwise specified, the information about LEDs applies to both ACX1000 and
ACX1100 routers.
•
System LED on the Front Panel on page 35
•
T1/E1 Port LEDs on page 35
•
Ethernet Port LEDs on page 36
•
SFP Port LEDs on page 36
•
Management and Console Port LEDs on the Front Panel on page 36
System LED on the Front Panel
One bicolor LED labeled SYS indicates the status of the router. Table 10 on page 35
describes the system LED in more detail.
Table 10: System LED on the Front Panel
DescriptionStateColorLabel
Router is transitioning online.BlinkingGreenSYS
Router is functioning normally.On steadily
Router has reported an alarm.BlinkingRed
Router has failed.On steadily
T1/E1 Port LEDs
The front panel of the ACX1000 router has eight T1/E1 ports, each with one pair of port
LEDs. Table 11 on page 35 describes the LEDs in more detail.
Table 11: T1/E1 Port LEDs
DescriptionColorLocationName
Online with no alarms or failures.GreenLeftLink
Active with a local alarm; router has detected a
failure.
Red
Not enabled.–
Online with alarms for remote failures.YellowRightLink
(remote
alarms)
35Copyright © 2017, Juniper Networks, Inc.
Chapter 2: Chassis Components and Descriptions
