Table 28: Management Port Connector Pinout Information
DirectionDescriptionPin
In/OutTRD[0]-1
In/OutTRD[0]+2
In/OutTRD[1]-3
In/OutTRD[1]+4
In/OutTRD[2]-5
In/OutTRD[2]+6
In/OutTRD[3]-7
In/OutTRD[3]+8
Related
Documentation
Console/Auxiliary Port Connector Pinout on ACX Series Routers on page 73•
USB Port Specifications for an ACX Series Router
The following Juniper Networks USB flash drives have been tested and are officially
supported for the USB port on all ACX Series routers:
•
RE-USB-1G-S
•
RE-USB-2G-S
•
RE-USB-4G-S
CAUTION: Any USB memory product not listed as supported for ACX Series
routers has not been tested by Juniper Networks. The use of any unsupported
USB memory product could expose your ACX Series router to unpredictable
behavior. Juniper Networks Technical Assistance Center (JTAC) can provide
only limited support for issues related to unsupported hardware. We strongly
recommend that you use only supported USB flash drives.
All USB flash drives used on ACX Series routers must have the following features:
•
USB 2.0 or later.
•
Formatted with a FAT or MS-DOS file system.
Related
Documentation
Initially Configuring the ACX2200 Router•
Copyright © 2017, Juniper Networks, Inc.74
ACX1000 and ACX1100 Universal Access Router Hardware Guide
